BD4CE-05 | 71" L | 3-Bowl Washing

Dipping Carts w/ Sink Combos

The BDCE series of ice cream carts are designed for easy scooping and equipped with a built-in sink ensuring a side-by-side seamless experience. Choose from 3 cooling options to keep food at the right temperatures. These carts are suitable for frozen novelties, food, drinks, or scooping from 3 gallon tubs while double-stacking for extra cold storage. Each stainless steel cart includes NSF-approved hand or utensil sinks, making them perfect for indoor sports arenas, conventions, and outdoor events ensuring long-lasting performance. Optional accessories make this model ready for any situation, even the summer heat!

*1 Year Warranty Parts & Labor
 Add a 4 year warranty on compressor parts for an additional $300.

4 Top Facing / 2 Cold Storage
Capacity 6 - 3 Gallon Tubs
& 3-Bowl Utensil Washing Sinks
Exterior Dimensions
71” L x 30.75 D x 50” H
Typical Lead Time
1-8 Weeks

Original price $0.00 - Original price $0.00
Original price
$0.00
$0.00 - $0.00
Current price $0.00

Specifications

BD4CE-05 & BD4CEDIP-05

6 Tubs & 3-Bowl Utensil Washing Sink Combo
Exterior Dimensions / 71” L x 30.75 D x 50” H
*Standard build tolerances apply.

4 Top Facing / 2 Cold Storage
Capacity 6 - 3 Gallon Tubs
Temp Range: Holds 0°F to +15°F
Voltage Freezer: 115V / 8 A
Optional Voltage Freezer: 220V / 4 A
Compressor: 1/3 HP

Sink Requires Separate Electricity
Stainless 3-Bowls / 21” x 13” x 5”
Individual Bowls / 6.25” x 12.25” x 5”
Sink Drain / 2” w/ Strainer & Stopper

Voltage Sink System: 120/1/60 V / 15 AMP CCT
Water Heater / 2.5 (Ariston, Model GL2.5)
Shurflo Pump: Series 8000 Diaphragm/ 115/1/60V / .61 fla /
1.7 gpm Free Flow w/ Pressure Shutoff
Supply Tank / 6 Gallons / Fill Port
Waste Tank / 9 Gallons / Overflow & Drain

Shipping Weight: 1000 lbs. (including crate)

Features

BD4CE-05 (Outdoor)
SS Flip Lid w/ Center Hinge & Square Sneeze Guard
BD4CEDIP-05 (Indoor)
SS Sliding Top Lids & Visual Dipping Sneeze Guard

- Stainless Steel Top
- Interior Stainless Steel
- Aluminum Base Frame
- Welded & Polished Corners / No Sharp Edges
- White Lexan Exterior Panels
- Poured Polyurethane Foam Insulation
- Lid Locks
- Bottom Defrost Drain
- Glide-out Condensing Unit Base
- 8’ Grounded 3-Wire Power Cord
- Electronic Programmable Temperature Control
- 6” Pneumatic Rubber Wheels / 2 Swivel w/ Brake / 2 Rigid
Wheel Load Rating Minimum of 350 lbs. ea.
- Removable Supply & Waste Tank (no tools required)
- Mesh Covered Fresh Water Overflow
- Door w/ Lock
- Soap Dispenser
- Paper Towel Dispenser

Added Features - (C) Model
- Built Into Cart Steel Eutectic Cold Plates
3 Cold Plate Temperatures:
• -12ºF / Frozen Novelties
• 0ºF / Ice Cream, Ices, Gelato & Slushies
• +26ºF / Refrigeration, Food & Drinks

Requires a 24 HR charge from room temperature.
Plugs in to recharge overnight in 12 HRS.
Holds for 10 HRS.

Accessories

Refrigerated (NCP) Model Only
- Eutectic Cold Packs 3 Temperature Options:
• -6ºF / Ice Cream & Novelties
• +3ºF / Ices & Gelato
• +26ºF / Refrigeration, Food & Drinks

- YD350011 / 20.75” L x 1” D x 12.75” H
- YD350012 / 12.75” L x 1”D x 10.75” H


Options

- Retractable Light Up Canopy / 78” closed – 96.25” open
Storage Shelf For Lightweight Products
Operator Side Pullout Shade
Canopy Styles: ¼ Round / ½ Round / Tent / Square

- Custom Artwork Panels - Inside Second Surface Printing
w/ Clear UV Coated Lexan (image won’t scratch/fade)

- YZ0396 / Dipper Well
- Solid Surface or Laminate Top
- Fold-Down Shelf 14” x 24”
- Hands-free Paper Towel Dispenser
- Quick Coupling Fill Valve

Recommend checking with the Health Department for approvals prior to purchase. Might require casters, permits, sink regulations for catering, private events, or serving dairy products.
