Specifications

16 DIP & 16 DIP-RB
16 DIP - 16 Display / 12 Cold Storage / Capacity 28 - 3 Gallon Tubs
16 DIP-RB - 16 Display / Capacity 16 - 3 Gallon Tubs

Exterior Dimensions / 88.25” L x 27.25” D x 51” H

16 DIP Interior Dimensions / 82.75” L x 21.50” D x 29.25” H
16 DIP-RB Interior Dimensions / 82.75” L x 21.50” D x 21.50” H
*Standard build tolerances apply.

Temp Range: Holds -10°F to +10°F
Compressor: 3/4 HP
Voltage: 115V / 10 A
Optional: 220V / 6 A

Shipping Weight: 750 lbs. (including crate)

Features

- Straight Glass Viewing Window
- Glass Canopy Construction
- Interior Stainless Steel
- Exterior White Enamel (Stainless Steel Upgrade)
- Welded & Polished Corners / No Sharp Edges
- Merchandising Flat Top Display
- Cold Wall Evaporators
- Anti-condensate Wire
- Poured Polyurethane Foam Insulation - Min .13 “K” Factor
- Forced‐air Tubular Clog Free Condenser
- PETG Lift Lids
- Frost Plates
- Night Covers
- LED Lights
- Manual Defrost & Operator Side Drain
- 7’ Grounded 3-Wire Power Cord
- Electronic Programmable Temperature Control

Raised Bottom (RB) Model
- Eliminates Pulling Heavy Tubs From Bottom
- Employee Side Breathing, Sits Flush Against Back Wall

Accessories

- N98112-CC / Can Clamp Kit (3 Gallon Rounds)
- N98112-16-G(4/5) / Gelato Racking Kit (4 / 5 Liters)
- N98112-16-R(2.5/3) / ROPAK Racking Kit (1.5, 2.5, 3 Gallons)
- N98112-16 / Can Skirting Kit (3 Gallon Cardboard Rounds)


Options

- N98006 / Set of (6) 3” Casters
- N98006-2” / Set of (6) 2” Dual Casters
- YZ0396 / Dipper Well
